12x12mm-Architectural-Top-Bend-LED-Neon-Flex
Bold Illumination in a Modern Square Profile. Strike the perfect balance between sleek design and powerful output with our 12mm x 12mm Top Bend LED Neon. While our mini-neon is designed for hiding, this 12x12mm profile is designed to be seen. It offers a substantial, uniform emitting surface that serves as a striking visual element in both indoor and outdoor environments.
Features and Benefits
- Architectural 12x12mm Square Profile
- Top-Bend (Vertical) Orientation
- Seamless, Dot-Free Illumination
- UV & Weather Resistant Silicone
- Robust IP65 / IP67 Waterproof Rating
- High Impact Resistance (IK08)
Downloads
Product Specs
| Connection Method | Solderless Connectors / Hard Wire |
|---|---|
| Dimmable | Yes |
| Customizable | Yes |
| Environment IP Rating | Indoor / Outdoor |
| Max Load Before Refeed | 96W (or up to 8m) |
| Certifications | ETL, CE, RoHS |
| Warranty | 5 Year Limited |
Dimensions: 12mm (W) x 12mm (H) square profile.
Bend Orientation: Top Bend (Vertical).
Weather Resistant: Encased in high-grade, UV-resistant silicone that withstands sun exposure, saltwater, and temperature shifts without yellowing or cracking.
Voltage: 24V DC (Optimized for longer continuous runs with stable brightness).
Cuttable: Marked cutting intervals for easy on-site customization.
IP Rating: IP65 or IP67 (Waterproof and dust-tight when end caps are properly sealed).
| Wattage | 12w/m |
|---|---|
| Voltage | 24V DC |
| CCT | 1800K, 2700K, 3000K, 4000K, 6500K |
| IP Rating | IP65, IP67 |
| SKU | Wattage | Voltage | CCT | IP Rating |
|---|---|---|---|---|
| 12x12TB-12W24V-18K-A | 12w/m | 24V DC | 1800K | IP65 |
| 12x12TB-12W24V-18K-B | 12w/m | 24V DC | 1800K | IP67 |
| 12x12TB-12W24V-27K-A | 12w/m | 24V DC | 2700K | IP65 |
| 12x12TB-12W24V-27K-B | 12w/m | 24V DC | 2700K | IP67 |
| 12x12TB-12W24V-30K-A | 12w/m | 24V DC | 3000K | IP65 |
| 12x12TB-12W24V-30K-B | 12w/m | 24V DC | 3000K | IP67 |
| 12x12TB-12W24V-40K-A | 12w/m | 24V DC | 4000K | IP65 |
| 12x12TB-12W24V-40K-B | 12w/m | 24V DC | 4000K | IP67 |
| 12x12TB-12W24V-65K-A | 12w/m | 24V DC | 6500K | IP65 |
| 12x12TB-12W24V-65K-B | 12w/m | 24V DC | 6500K | IP67 |
